Hardwired power converter for up to: (8) ZEMS or ZEMS-IS sensors/actuators, or (8) ZESS sensors/solenoids, or (8) sensor faucets, or (8) Pint urinal valves.
Power output is 7.6 VDC regulated FOR 6V FIXTURES. Input Voltage: 110-240V, 50/60Hz, 2.0A
- Electrical box is 4” Wide x 4” Tall x 2 1/8” Deep .
- Powers up to 8 hardwire-fitted sensors.
- Hardwire-powered sensors reduce maintenance expenses by eliminating the need to replace batteries.
Architectural Specification:
ZURN P6000-HW6 Power Converter - The Hardwired Power Converter is a 7.6 VDC regulated, 2.0A power supply that will operate up to: (8) ZEMS or ZEMS-IS Sensors/Actuators, (8) ZESS Sensors/Solenoids, (8) sensor faucets, or (8) Pint Urinal valves. The unit shown above is integrated into a 4"L x 4"W x 2-1/8"D electrical box. The AC input connections are terminated within the electrical box. The 7.6 VDC output terminals are externally mounted to the cover plate.
Warnings:
