ASI 10-9343 Stainless Steel Push Button Soap Dispenser, Wall/Surface Mount,

SKU: 10-9343
(No reviews yet) Write a Review
$68.70
Adding to cart… The item has been added
Important note icon

Please note this dispenser is NOT compatible with Hand Sanitizer.

All-purpose valve dispenses liquid, lotion and detergent-type soaps, with a capacity of 48 fl. oz. (1.4 L). It has a tamper-resistant refill window with concealed fastening and vandal-resistant hinged filler-top.

Soap Requirements: Proper usage of this dispenser requires, that only soap within the following range for viscosity and pH may be used.

> Viscosity Range (mPa·s or cP): 100 – 2500
> pH Range: 5.5 ~ 8.0
Architectural Specification:

Profile Collection Surface Mounted Soap Dispenser shall have a capacity of 48 fluid oz. (1.4 liter) of liquid or lotion soaps, synthetic detergents and antibacterial soaps containing PCMX and/or Triclosan. Dispenser shall be fabricated of alloy 18-8 stainless steel, Type 304, 20 gauge. All exposed surfaces shall be No 4 satin finish. Valve shall be constructed of a plastic valve body and push button with stainless steel and plastic internal parts. Valve operation shall comply with ADA Accessibility Guidelines by requiring no more than 5 lbsf (22.2 Newtons) pressure to actuate and require no grasping or twisting by operator. A tamper resistant sight gauge shall be provided. Unit shall have a hinged stainless steel refill door on top which is opened with special key provided.
