One-piece, 1/2" x 1/2" x 3/8" (13 x 13 x 9.5mm) channel-frame. Type-430 stainless steel with bright-polished finish. Mitered corners. Frame screw permits easy replacement of glass. 1/4" (6mm) tempered glass mirror. Galvanized steel back. Secured to concealed wall hanger with theft-resistant mounting. Tempered glass mirrors resist breakage and provide a measure of safety from broken glass, but differ in color and reflective quality from standard glass mirrors. Bobrick uses the highest quality tempered glass mirrors. Modest distortion or heat-generated markings are normal in the tempered glass mirror manufacturing process. Therefore, Bobrick will not accept returns of tempered glass mirrors with random distortion or markings.
Measurement Diagram:
Architectural Specification:
Mirror shall have a one-piece Type-430 stainless steel channel frame, with 90° mitered corners; all exposed surfaces shall have bright polished finish. Mirror shall be __________________________ (insert one: polished stainless steel, tempered glass, or laminated glass). Backs of all glass mirrors shall be protected by full-size, shock-absorbing, water-resistant, nonabrasive, thick polyethylene padding. Galvanized steel back shall have integral horizontal hanging brackets located near top for mounting on concealed wall hanger.
