ASI 10-0535-2430 Mirror, Fixed Tilt, Stainless Steel Frame, 24" W x 30" T ( 4"D@Top, 1" D@Bot)

SKU: 10-0535-2430
(No reviews yet) Write a Review
$354.25
Availability:
Ships in 2 business days from manufacturer.
Adding to cart… The item has been added
Free shipping image
Important note icon

Top extends 4" away from the wall and gradually decreases down to 1" out at the bottom.

Offers visibility for wheelchair patients. Frame fabricated of 20 gauge stainless steel with a satin finish. Mirror is tapered from 4″ (102 mm) at top to 1″ (25 mm) at bottom.

> 0535-2430 – 24” wide x 30” high (610 x 762 mm)

Measurement Diagram:

Measurements for ASI 10-0535-2430 Mirror
Architectural Specification:

Fixed Angle Tilted Mirror shall be fabricated of alloy 18-8 stainless steel, type 304, 20 gauge. Face shall be one piece construction free of miters or spot welded seams. All exposed surfaces shall have No 4 satin finish and be protected during shipment by plastic PVC film easily removable after installation. Concealed tamper resistant locking devices shall be provided. Mirror shall be _______(INSERT GLAZING OPTION) and shall be warranted for 15 years against silver spoilage. Mirrors shall be supplied as standard with glazing option ‘ A ´. For a complete description and other choices of glazing options, see the Mirror Glazing OPTIONS Chart.

!
