ASI (10-0191-1-93) High Speed Stainless Steel Hand Dryer
 | SPECIAL PRICING! This product is currently available for introductory pricing. Normally 295.00. |
Highly economical, stainless steel, surface mount, high speed hand dryer. Heavy duty, one piece cover with brushed metal finish. 15 Second dry time! This is the perfact hand dryer for small bathrooms with limited space.
Heavy duty one piece stainless steel construction with ABS end caps.
Fast 15 second dry time.
Comfortable warm air output.
Vandal resistant features including tamper resistant nozzle and protected air intake path.
Motor and heating element have internal thermal (self resetting) protection.
Long life brush type motor with dual ball bearings.
Certifications:
Measurement Diagram:
| Reported Dry Time: | 15 Seconds |
| Mount: | Wall / Surface |
| Cover: | Stainless Steel, Brushed Finish |
| Nozzle: | Concentrated Single Port |
| Activation: | Automatic (infra-red) hands-free (self calibrating) |
| Power: | 1350 Watts, 110-120V (12A) |
| Motor: | Brush type, dual ball bearings |
| Fan: | Multi-inlet centrifugal |
| Airspeed: | 152 MPH |
| Reported Sound Level: | Not published |
| Heating Element: | Nichrome wire (thermally protected) |
| Filter: | None |
| IP Rating: | Not published |
| Product Dimensions: | 6-1/32" Wide x 11-1/32" Tall x 6-3/8" Deep |
| Product Weight: | Approx. 8 lbs. |
| Shipping Dimensions: | Approx. 12" Length x 8" Width x 8" Height |
| Shipping Weight: | Approx. 9 lbs. |
| UPC / GTIN: | Not published |
| Manufacturer's Part No.: | 10-0191-1-93 |
| Country of Manufacture: | Taiwan |
Architectural Specifications:
Surface Mounted High-Speed Hand Dryer with IR sensor activates upon placed objects in sensing zone. Motor and heating element shall have internal resetting automatic thermal protection. Unit features heated air and a drying time of less than 15 seconds. Heavy-duty, one piece cover is formed from 3/64" [1,0] thick satin finished stainless steel. Fixed directional air nozzle shall be heavy-duty, rust proof and highly tamper resistant. Air intake slots do not allow access to internal parts. Circuitry has self-adjusting time-out and fail-safe off protection controlled by a microprocessor that detects and rejects false signals and automatically self-calibrates to provide uniform sensitivity over its entire life span. Entire unit is internally electrically grounded. Dryer unit is C-UL-US® and CE approval and listed under Underwriters Laboratories, Inc. Unit is warranted against defects in materials or workmanship for one (1) year.
UNIT SIZE: 6-1/32" W x 11-1/32" H x 6-3/8" D (153 x 280 x 162 mm)
